Steel Coil Handling Cranes

(Steel Coil Handling Cranes)

INTRODUCTION

A coil and plate handling crane （Coil and plate handling cranes） handles metal bars, plates, and coils during machining processes. They can be designed for both indoor and outdoor use. Due to the wide variety of materials they need to handle, such a crane can be fitted with a variety of lifting devices that change with the nature of the material.

weihua coil and plate handling crane (steel coil crane) is designed for traveling a long distance quickly to keep duty cycles short using specialized hook extensions for plates, tubes, rolls or coils up to 80 tons. It can be equipped with Smart Features such as Load Positioning, Sway Control, and Overload Protection to shorten handling times, reduce wear on the crane, extend its life and speed up workflow. Tailoring provides you with attachments for any steel products, and additional capacity, as per your requirements.

We have always maintained the safety production first, the most important production requirements of customer needs.

Related product links:

①Metallurgy Cranes

②Steel And Metallurgy

③Ladle Cranes

④Metallurgical Overhead Crane

⑤Forging Crane

⑥Billet Clamp Crane

⑦Electromagnetic Beam Crane

Weihua automated intelligent steel coil handling crane (steel coil crane) is an integrated management system with information technology, artificial intelligence, digital twins, big data, industrial Internet and sensor technology. It adopts advanced software design concepts of modularity, openness, and generalization, achieving intelligent and unmanned operation of the steel coil handling management.

Our intelligent steel coil handling crane （Coil and plate handling cranes）are not only equipped with high-precision anti-sway, positioning, laser scanning and other hardware systems, but also a powerful, information-rich, and smooth-running control system, which can easily respond to various needs of intelligent material handling.

Detailed Photos

Main Features of Weihua automated intelligent steel coil handling crane

1. This crane can be equipped with a variety of lifting devices like coil grab( C-hook) and magnets depending on the material to be handled, the slewing function can be provided.

2. The crane can be controlled with a radio remote controller or in a cabin. Manual, semi-automated and fully-automated functions can be provided and the control mode can be switched freely.

3. Visual Recognition System. The designed visual recognition system with functions of scanning and recognition of vehicle information and steel coils, precise positioning and realization of intelligent unmanned automatic loading and unloading trucks and safety protection in the working area.

4. Anti-sway System. Ground infrared equipment is interconnected with the crane to control the swing, the handling process is smooth and efficient.

5. Data Cloud Platform. The platform including visual warehouse management scheduling system, warehousing data management system, intelligent production line scheduling system and equipment condition monitoring system, all can be connected to all intelligent warehouse management systems.

Specification

Technical Specifications

Lifting Capacity		t	16+16
Span		m	26.5
Lifting Height		m	7
Work Duty			A7
Speed	Lifting	m/min	1.2~12
	Crane Traveling		6.2~62
	Trolley Traveling		20.6
Power		KW	315
Max Wheel Load		KN	295
Recommand Track			QU100
Power Supply			3 Phase A.C.50Hz 380V
